ASROCK B850 RIPTIDE WIFI AM5 ATX 4X DDR5

0.0 No reviews yet Write a review
SKU: B850-RIPTIDEWIFI
New Supplier has stock — 8 avail

ASRock B850 Riptide WiFi ATX motherboard for AMD Ryzen AM5, with four DDR5 slots, four NVMe sockets, Killer 2.5 GbE and Wi-Fi 7.

R5,989.00

VAT included · Secure checkout

Supplier has stock — 8 avail

Key product details

Full specifications below
  • Mpn: B850-RIPTIDEWIFI
  • Brand: ASRock
Add to wishlist

Delivery & support

Clear fulfilment, warranty and payment details.

  • Availability Supplier has stock — 8 avail Supplier has stock — 8 avail
  • Delivery Nationwide courier delivery or collection from Strand, Cape Town. Courier nationwide or Strand collection
  • Dispatch Backorder — usually dispatched in 2–3 working days after payment verification, subject to supplier confirmation. Backorder — usually dispatched in 2–3 working days after payment verification, subject to supplier confirmation.
  • Warranty Manufacturer warranty applies where stated on the product page. As stated on this page
  • Returns See our Returns Policy for eligible change-of-mind and faulty goods procedures. See Returns Policy
  • Secure payment PayFast checkout with card, Instant EFT, and Mobicred. PayFast · card · EFT · Mobicred
Ask us a question

Official manufacturer overview

ASRock AMD B850 motherboard family overview

ASRock Global · Family overview of ASRock’s AMD B850 range, which includes this ATX B850 Riptide WiFi. The film covers several boards with different features and connectors.

Play to load this video from YouTube.

ASRock Phantom Gaming | AMD B850

Room for four NVMe drives on AM5

The ASRock B850 Riptide WiFi is a full-size ATX motherboard for supported Ryzen 7000, 8000 and 9000 processors. Four DDR5 slots sit alongside four NVMe sockets, two full-length expansion slots and wired and wireless networking. Choose your processor and expansion layout together to get the lanes your build needs.

ASRock Phantom Gaming B850 Riptide WiFi ATX motherboard beside its purple retail box and antenna
AM5Ryzen platform
256 GBMaximum DDR5
4 × M.2NVMe sockets
Wi-Fi 7Windows 11

Processor and firmware

Choose your Ryzen chip before setting up the board

Check the exact ASRock CPU support entry and minimum UEFI before installation. The rear BIOS Flashback button lets you prepare the board with the correct USB file and power supply even before the CPU and memory are installed. The 14+2+1 phase design and eight-layer PCB are part of the board’s power and signal design.

Memory layout

Start a two-module build in A2 and B2

Use a matched DDR5 pair in A2 and B2 for dual-channel operation. The board supports up to 256 GB across four unbuffered slots. ASRock lists DDR5-8000+ as an overclocking capability. Actual speed depends on the processor, DIMM kit, slot population and firmware. Check the qualified-memory list before choosing a high-capacity or four-DIMM kit.

Expansion and storage

Reserve the lower slot if you need an add-in card

Put your primary NVMe SSD in M2_1. Installing an SSD in M2_4 disables PCIE2, the lower full-length slot wired for PCIe 4.0 ×4. Ryzen 8000 models can also reduce the lanes or generation available to the graphics slot and some CPU-connected SSD sockets. The original build conveniences include an enlarged graphics-card release latch and a removable M.2 heatsink.

Connections for daily use

Wire the desk and choose the network that suits it

The rear panel gives you Killer 2.5 Gigabit Ethernet, two 10 Gb/s USB-C ports and HDMI for supported processor graphics. The case can add a 20 Gb/s front USB-C port if wired to the corresponding header. Wi-Fi 7 and Bluetooth 5.4 are built in. ASRock supports the Wi-Fi module on Windows 11, with 6 GHz availability dependent on the local rules and network.

Cooling and lighting

Plan connectors before closing the case

Use an ATX-compatible case and connect the 24-pin main board power and suitable 8-pin CPU leads. Separate CPU, chassis and pump headers give you control of the cooling layout. Keep 12 V RGB and 5 V addressable devices on their matching headers. ASRock lists Polychrome Sync and SignalRGB support for compatible devices.

Specifications

Platform, firmware and fit

ModelASRock Phantom Gaming B850 Riptide WiFi, ATX
Socket and chipsetAMD AM5, AMD B850
Processor familiesSupported AMD Ryzen 7000, 8000 and 9000 series. Check exact processor and minimum UEFI against ASRock CPU Support.
UEFI and updates256 Mb AMI UEFI, ASRock Instant Flash and rear USB BIOS Flashback
Board dimensions305 × 244 mm, 8-layer PCB
Power design14+2+1 phases, 80 A Dr.MOS for VCore and SoC as listed by ASRock
Power headers1 × 24-pin ATX and 2 × 8-pin 12 V CPU
Listed warranty36 months on this offer

DDR5 memory

Sockets and channel layoutFour 288-pin DDR5 DIMM slots, dual channel
Memory populationStart with A2 for one DIMM. Use A2 and B2 for two matched DIMMs. Four modules occupy A1, A2, B1 and B2.
Maximum capacity256 GB system total. Check exact part capacities, rank and supported slot population on the CPU-specific memory list.
Supported modulesECC or non-ECC unbuffered DDR5. Check CPU and memory qualifications for ECC operation.
Memory profiles and ratesAMD EXPO and Intel XMP. Up to DDR5-8000+ (OC) as listed by ASRock, depending on the exact CPU, DIMM kit and configuration.

Graphics, NVMe and SATA

Top expansion slot PCIE1CPU-connected full-length slot. PCIe 5.0 ×16 with Ryzen 7000/9000, PCIe 4.0 ×8 with Ryzen 8000 Phoenix 1 or PCIe 4.0 ×4 with Phoenix 2.
Lower expansion slot PCIE2Chipset-connected PCIe 4.0 ×4 in a full-length socket. M2_4 occupancy disables PCIE2.
M2_1CPU-connected 2280 NVMe, PCIe 5.0 ×4 with Ryzen 7000/9000 and PCIe 4.0 ×4 with Ryzen 8000.
M2_2CPU-connected 2260/2280 NVMe, PCIe 4.0 ×4 except PCIe 4.0 ×2 with Ryzen 8000 Phoenix 2.
M2_3Chipset-connected 2230/2260/2280 NVMe, PCIe 4.0 ×4.
M2_4Chipset-connected 2260/2280 NVMe, PCIe 4.0 ×4. Occupies the path shared with PCIE2.
SATA and boot support4 × SATA 6 Gb/s via ASMedia ASM1061. Supports NVMe boot and NVMe RAID 0, 1 and 10.
HDMIHDMI 2.1 TMDS/FRL 8G compatible, with HDR, HDCP 2.3 and up to 4K at 120 Hz when supported by the processor and display.

Network, USB and audio

EthernetKiller E3100G with 10/100/1000/2500 Mb/s link modes
Wireless2×2 Wi-Fi 7 (802.11be), 2.4/5/6 GHz bands, and Bluetooth 5.4. Uses a vertical M.2 Key E 2230 Wi-Fi/BT slot.
Operating systemsASRock lists Windows 10/11 64-bit for the board. The built-in Wi-Fi 7 module requires Windows 11. 6 GHz band availability depends on local regulations and updates.
Rear USB2 × USB-C at 10 Gb/s, 2 × USB-A at 10 Gb/s, 3 × USB-A at 5 Gb/s and 4 × USB 2.0
Front USB headers1 × front USB-C at 20 Gb/s, 2 × USB 3.2 Gen 1 headers for four 5 Gb/s ports and 2 × USB 2.0 headers for four ports
AudioRealtek ALC4082 7.1-channel HD Audio, Nahimic, rear optical S/PDIF, line out and mic in. ASRock specifies front headphone support up to 600 Ω.
Other rear connectionsTwo antenna ports, integrated I/O shield, HDMI, RJ-45 and BIOS Flashback button

Internal headers, cooling and accessories

Fan and pump headers2 × CPU, 3 × chassis and 1 × AIO pump, all 4-pin. CPU_FAN1 up to 1 A/12 W. CPU_FAN2, chassis and AIO pump up to 3 A/36 W each.
Lighting headers1 × 12 V RGB at up to 3 A total and 3 × 5 V addressable RGB at up to 3 A total
Other headers and toolsSPI TPM, front audio, thermistor, front-panel LED/speaker, ASRock Post Status Checker and integrated I/O shield
Manufacturer utilities and lightingASRock Phantom Gaming Tuning, Killer Control Center, Polychrome Sync, SignalRGB support on compatible equipment and ASRock Auto Driver Installer
Board accessories listed for this offerTwo SATA data cables, two 2.4/5/6 GHz antennas, one ARGB splitter and one thermistor cable
Compliance listed by ASRockFCC and CE. ErP/EuP readiness requires a suitable PSU.

Check the exact Ryzen processor, UEFI, DIMM kit and M2_4 or lower PCIe slot usage before finalising the build.
