Official manufacturer overview
Ubiquiti U7 Pro XG and XGS family overview
Ubiquiti · Ubiquiti introduces both access points. This listing is for the six-stream U7 Pro XG with PoE+ power. The eight-stream radio configuration, dedicated spectrum scanning and PoE++ power shown for the XGS apply to that model.
Play to load this video from YouTube.
Ubiquiti UniFi U7 Pro XG · White
Ceiling-mounted Wi-Fi 7 with a 10 GbE uplink
The white U7 Pro XG adds three Wi-Fi radios to a managed UniFi network. Its 10 GbE port carries the wired uplink and PoE+ power over the same Ethernet cable, so the round access point can sit on the ceiling with the wiring behind it.

Wireless design
Two spatial streams per band
Separate 2.4, 5 and 6 GHz radios provide six spatial streams in total. The 6 GHz band supports channels up to 320 MHz where enabled. Usable channels and client performance depend on the country configuration, client hardware and the installation.

Wired backhaul
One cable for data and power
The RJ45 port supports 10, 5, 2.5 and 1 GbE link rates with suitable network equipment. Supply PoE+ and allow up to 22 W per access point when budgeting switch power.

Installation
Fit it to the ceiling or wall
The included Lite Mount supports ceiling and wall installation. The enclosure measures 206 mm across and is 32.5 mm deep. Use the official guide to check cable routing and the mounting steps.

Management
Adopt and configure in UniFi Network
The white U7 Pro XG requires UniFi Network 9.0.114 or later. Network controls include guest isolation, VLAN assignment and roaming assistance for compatible clients.
