Huawei eKitEngine S110-16LP2SR · Gigabit PoE+
Sixteen PoE+ ports, two dedicated uplinks
Bring data and power to compatible Ethernet devices through sixteen Gigabit PoE+ ports. Two GE SFP uplink slots and a built-in AC supply give this unmanaged switch a focused role at the network edge, with a shared 124 W PoE budget.

Device connections
Sixteen copper ports for the access layer
Each copper port supports 10/100/1000BASE-T networking, with PoE+ available for compatible powered devices. The two separate GE SFP uplink slots keep the uplink connections distinct from the sixteen device ports. Choose compatible transceivers and cabling for the intended link.
PoE planning
Build the power plan around a shared budget
Huawei specifies a 124 W PoE budget for this model. Plan the combined requirements of the connected powered devices against that total, rather than treating every port as a separate 124 W supply. The built-in AC power supply is listed with maximum consumption of 22 W without PoE and 160 W at full PoE load.
Switching role
Unmanaged operation with four working modes
The S110 series is designed for configuration-free, unmanaged switching. The manufacturer lists standard mode, port isolation, port bonding and flow-control disabling for this model group. Huawei rates the S110-16LP2SR at 36 Gbit/s switching capacity and 26.78 million packets per second; these are switching specifications, not a measured internet-access rate.
Cooling and installation
A fanless chassis for a planned installation
Natural heat dissipation removes the need for a cooling fan. The exact manufacturer model page lists rack, desk and wall mounting options. The body measures 43.6 × 442 × 260 mm, with maximum depth of 267 mm including protruding parts; allow space for the intended mounting arrangement and connected cables.
Environmental reference
Check the operating conditions before placement
The series data sheet lists 0°C to 45°C operation for this exact model at altitudes up to 1,800 m. Above that level, the maximum operating temperature is reduced according to the manufacturer’s altitude rule in Specifications. Keep the thermal and mounting requirements part of the installation plan.
