Gigabyte B760M DS3H DDR5 LGA 1700 mATX Motherboard

0.0 No reviews yet Write a review
SKU: MB-GB760MDS3HD5
New In Stock with Supplier 2 — 1 avail

GIGABYTE B760M DS3H LGA1700 DDR5 micro-ATX motherboard with two Gen4 M.2 slots, 2.5Gb Ethernet and 10 Gb/s rear USB-C.

R2,969.00

VAT included · Secure checkout

In Stock with Supplier 2 — 1 avail

Key product details

Full specifications below
  • Mpn: MB-GB760MDS3HD5
  • Brand: Gigabyte
Add to wishlist

Delivery & support

Clear fulfilment, warranty and payment details.

  • Availability In Stock with Supplier 2 — 1 avail In Stock with Supplier 2 — 1 avail
  • Delivery Nationwide courier delivery or collection from Strand, Cape Town. Courier nationwide or Strand collection
  • Dispatch Backorder — usually dispatched in 2–3 working days after payment verification, subject to supplier confirmation. Backorder — usually dispatched in 2–3 working days after payment verification, subject to supplier confirmation.
  • Warranty Manufacturer warranty applies where stated on the product page. As stated on this page
  • Returns See our Returns Policy for eligible change-of-mind and faulty goods procedures. See Returns Policy
  • Secure payment PayFast checkout with card, Instant EFT, and Mobicred. PayFast · card · EFT · Mobicred
Ask us a question

GIGABYTE B760M DS3H | DDR5 micro-ATX

Four DDR5 slots and dual NVMe in a 244 mm square

Build a compact Intel desktop with the GIGABYTE B760M DS3H. The micro-ATX layout combines four DDR5 memory sockets, two Gen4 M.2 positions and a 2.5Gb Ethernet port. The rear panel offers two DisplayPort outputs alongside HDMI and VGA for processors with compatible graphics.

GIGABYTE B760M DS3H DDR5 micro-ATX motherboard next to its black Ultra Durable retail box
244 × 244 mmMicro-ATX form factor
2 × M.2Gen4 NVMe sockets
2.5GbEWired Ethernet
10 Gb/sRear USB-C

CPU and BIOS

Start with the exact LGA1700 processor and BIOS

GIGABYTE lists supported 12th, 13th and 14th Gen Intel Core chips for its rev. 1.0 board. Check the CPU support list for the BIOS needed by the processor you choose. The Q-Flash Plus function is available for a board update, using firmware for the exact PCB revision.

Memory

Fit a matched kit before filling all four sockets

For a two-module kit the manual recommends A2 and B2. The existing listing specifies 128 GB. Check the board’s revision, CPU and BIOS against GIGABYTE’s memory support list before choosing a higher capacity or an overclocked rate.

Drives and expansion

Choose where the system drive connects

Each M.2 socket accepts an M-key 2280 PCIe drive. One connects to the CPU and the other to the chipset. The main slot uses PCIe 4.0 x16, while two separately wired PCIe 3.0 x1 slots are available for compatible cards. Four SATA sockets remain available for SATA storage.

Display and rear I/O

Connect newer and older screens

Use the board’s two DisplayPort sockets, HDMI or VGA with a processor that supports integrated graphics. GIGABYTE specifies up to four simultaneous displays for supported configurations. Rear USB-C reaches 10 Gb/s, and the RJ45 port is rated to 2.5 Gb/s on compatible wired equipment.

Specifications

Platform and fit

ModelGIGABYTE B760M DS3H, DDR5 non-AX edition
Chipset / socketIntel B760 Express, Intel LGA1700
Processor families (rev. 1.0)Supported Intel 12th, 13th and 14th Gen Core, Pentium Gold and Celeron. Check CPU and BIOS support list.
BIOSAMI UEFI with Q-Flash and Q-Flash Plus. Use files matching the exact PCB REV marking.
Form factorMicro-ATX, 244 × 244 mm
Power connectors24-pin ATX plus 8-pin ATX12V

Memory

Memory sockets4 × DDR5 UDIMM, dual channel, Intel XMP support
Capacity in the existing listing128 GB across four DIMM sockets
Capacity in GIGABYTE’s current rev. 1.0 documentationUp to 256 GB with supported 64 GB DDR5 modules, a supported CPU, BIOS and slot population. The supplied board revision and installed BIOS are unconfirmed.
Speed (GIGABYTE rev. 1.0 specification)Up to DDR5-7600 MT/s (OC). The CPU and installed DIMMs determine supported speeds.
Memory populationUse A2 and B2 for a two-module kit. Check the GIGABYTE memory list for the intended kit and number of DIMMs.
ECC modeSupported ECC unbuffered DIMMs run in non-ECC mode.

Expansion and storage

Main expansion1 × PCIe 4.0 x16 wired x16 from CPU. GIGABYTE lists graphics cards or NVMe SSDs for this slot.
Auxiliary expansion2 × PCIe 3.0 x1 from B760 chipset
CPU M.2M2A_CPU, M-key 2280 PCIe 4.0 x4/x2
Chipset M.2M2P_SB, M-key 2280 PCIe 4.0 x4/x2
SATA4 × SATA 6 Gb/s with SATA RAID 0/1/5/10 support

Rear connectors

USB1 × USB-C 10 Gb/s, 3 × USB-A 5 Gb/s, 2 × USB 2.0
Display2 × DisplayPort 1.2 up to 4096 × 2304 at 60 Hz, 1 × HDMI TMDS up to 4096 × 2160 at 60 Hz, 1 × VGA up to 1920 × 1200 at 60 Hz. Graphics support depends on CPU.
NetworkRealtek 2.5GbE RJ45 (2.5 Gb/s, 1 Gb/s, 100 Mb/s)
Legacy and audioPS/2 keyboard/mouse, 3 audio jacks; Realtek HD Audio up to 7.1 with configuration

Headers and software

Case USB1 × USB 3.2 Gen 1 header for two ports, 2 × USB 2.0 headers for up to four ports
Cooling1 × CPU fan, 3 × system fan
Lighting and system1 × addressable LED, 1 × RGB, front panel and audio, serial, parallel, S/PDIF, compatible SPI TPM, reset and Clear CMOS
OS supportGIGABYTE lists Windows 10 64-bit and Windows 11 64-bit

Original image depicts the DDR5 motherboard and box. Official direct guide is a family manual; its DDR5/non-AX callouts were used for memory population evidence. Did not infer physical model from the product code alone.
