DELL 338-CBXX · XEON SILVER 4314
Build the server around sixteen capable cores.
Dell 338-CBXX brings the Intel Xeon Silver 4314 into a qualified server configuration. Its 16 cores and 32 threads, 2.40 GHz base frequency and 24 MB cache define the processor at the centre of the upgrade. Plan memory, expansion, power and cooling around the exact Dell server.

Cores and clocks
Sixteen cores for concurrent server work
The Xeon Silver 4314 provides 16 physical cores and 32 threads with Hyper-Threading, a 2.40 GHz base frequency and 24 MB of cache. Its maximum Turbo frequency is 3.40 GHz under the required power, temperature and workload conditions. Turbo is not an all-core sustained-frequency guarantee, and application results depend on the complete server.
Memory architecture
Eight channels, with server-level planning
The processor supports eight DDR4 memory channels and ECC memory. Intel specifies DDR4-2667 and a processor memory ceiling of 6 TB, dependent on memory type. Dell labels this offer DDR4-2666. These are processor specifications: the actual Dell system determines supported DIMM types, slot populations, capacity and achievable memory speed. Existing faster DIMMs do not make this processor run at their full rated speed.
Expansion and virtualisation
Connect the platform around the workload
PCI Express 4.0 support and up to 64 processor lanes provide the CPU-side expansion resources for a qualified server platform. The motherboard determines which slots and devices receive those lanes. Intel VT-x virtualisation and the Dell-listed VT-x with Extended Page Tables support virtualised environments when enabled by the system and software.
Fit and cooling
Match the Dell part to the complete server
This offer is Dell 338-CBXX, matched to manufacturer part 94J0F and Xeon Silver 4314. The processor uses FCLGA4189 and has a 135 W thermal design power. Socket fit alone does not establish compatibility: check the exact server model and configuration, BIOS support, processor pairing, power budget and approved cooling hardware. Use Dell-approved heatsink and mounting hardware for the exact chassis and processor configuration.
