AMD RYZEN 9 9950X3D · BOXED AM5
Sixteen Zen 5 cores with 128 MB of L3 cache
The Ryzen 9 9950X3D combines 16 Zen 5 cores, 32 threads and 128 MB of L3 cache. It uses the AM5 socket, supports DDR5 and includes integrated Radeon graphics. This boxed part is supplied without a cooler.

PROCESSOR
Match the boxed order number
AMD identifies this box as 100-100000719WOF. It has a 4.3 GHz base clock, up to 5.7 GHz maximum boost, 16 MB L2 and 128 MB L3 with second-generation AMD 3D V-Cache.
PLATFORM
Check BIOS and memory support before assembly
Select an AM5 board with BIOS support for the exact 9950X3D. AMD lists DDR5-5600 with two DIMMs and DDR5-3600 with four in its standard memory table; actual capacity and speeds depend on the board and memory.
GRAPHICS AND PCIe
Plan the board’s display outputs and expansion
The processor provides Radeon integrated graphics and PCIe 5.0 support. Which physical outputs and slot speeds are available depends on the motherboard.
COOLING
Choose the cooler separately
AMD lists a 170 W default TDP and recommends liquid cooling for optimal performance. This boxed WOF part does not include a cooler.
